Our Technology

Patented & Proprietary

Intelicid is a patented technology that revolutionizes acid treatments with unmatched precision and efficiency. Its unique design, protected by patent, ensures targeted acid delivery, maximizing treatment effectiveness while minimizing environmental impact. This innovative solution reduces operational costs and sets a new industry standard for reliability and performance in oil and gas acidizing.

How we stand apart

The Intelicid Process

01

QUick and easy rig up on site

The Intelicid system features the industry's fastest rig-up process, slashing traditional setup times in half with our cutting-edge optimization and state-of-the-art automation.

02

Closed System Eliminates Toxic Fumes

Our system is meticulously designed with a vapor-sealed mechanism and an integrated scrubber system, ensuring the complete elimination of hazardous vapors on-site. This advanced feature guarantees a safer working environment by actively preventing the release of any harmful gases during operations.

03

Precision Mixing: Less than 1% Variance

Our acid mixing system revolutionizes precision with less than 1% variance in measurement, dramatically outperforming traditional methods with variances of 3-5%. This leap in accuracy ensures optimal chemical utilization, boosts well performance, and markedly enhances cost efficiency, setting a new standard in operational control and consistency.

04

Operate Anywhere: Single-Operator Remote Control

Engineered for flexibility, allowing operation directly from the unit itself or through a remote operator's box, seamlessly integrating with Data Van or Pump Down systems. This dual-mode functionality ensures operational adaptability, catering to various field conditions and requirements, and enhances control and efficiency.

05

Smart Data Utilization: Saving Resources

The unit is designed to have preset concentration, volume, and flush amounts to clear all lines on location of any potential hazardous chemicals in the event hoses need to be rigged down.

06

Adaptive Technology: Accumulating Data

Unit is cloud-enabled and stored for post job reports being sent to data van or historically pulled up after the fact.

07

Eliminated Waste: No Heavy Pumping or Disposal

Our innovative system is engineered to significantly reduce environmental impact by eliminating the need for heavy pumping and minimizing waste disposal requirements. By optimizing operational efficiency, it not only conserves resources but also lowers the ecological footprint of drilling operations.

Benefits

The benefits of the Intellicid allow us automate the entire system, it is cloud enabled, and has many more benefits to make your project prgress smoothly

Safety

The Intelicid System significantly enhances operational safety by automating the acid mixing process, substantially reducing the need for direct human involvement and exposure to hazardous chemicals. This reduction in manpower not only mitigates the risk of accidents and injuries but also exemplifies a commitment to creating safer work environments in the oil and gas industry. With its precise control and automation, the system minimizes operational errors, aligning efficiency with safety and showcasing a forward-thinking approach to protecting workers while maintaining high operational standards.
Benefits
Safety

Fully Automated System

 eliminating human error in strap stick readings and manually adjusting valves​

System is Cloud enabled

with real time data that can be uploaded to any frac software for post job reports​

Field Trials with EOG

have proved a +/- .25% target concentration​

Precision Control

With variable acid concentration adjustment from 5% - 36% on demand, secured with optional password protection to prevent unintened modifications

Vapor sealed

with a scrubber system to eliminate all hazardous vapors on location​

System is enabled to swap from Acid to Water

via electric controlled valves eliminating the need to have a human being in the Red/Danger zone while pumping operations are being done

Advanced tank level pressure sensor and temperature probe

that ensure precise acid concentrations and specific gravity adjustments, delivering cost savings through increased accuracy and efficiency in acid use

Fully automated

with double redundancies on both manual and automatic valves​

Flexible operation

from the unit or through a remote operator's box for Data Van or Pump Down integration

Holding 21,000/gal of 36% food grade acid

gives the unit the ability to hold 55,402 gallons of 15% HCl equivalent in a smaller footprint as the current 2 open to the atmosphere acid tank set up currently being used in the field today​
Equipped with a vapor-sealed bulk tank with a liner specifically for continuous 40% HCl
Designed for safety and efficiency, our unit automatically clears all lines of hazardous chemicals after reaching the preset acid volume, ensuring a clean, ready-for-next-use system without manual cleaning
Incorporates Pressure and Vacuum Relief valves to maintain tank integrity throughout operations
Equipped with a vapor scrubber system to eliminate any hazardous vapors from leaving the tank during filling of the unit​
Effortlessly transitions between acid and water, negating the need for on-site staff to access danger zones or don specialized safety equipment
Equipped with both manual and automated valves, our system offers dual-layer security, ensuring uninterrupted operation and immediate response capability in any emergency scenario
Enhanced to store a greater volume of 15% acid equivalent, reducing on-site transport congestion and minimizing accident risks
